Products – Dermavent

BREATHABLE

MEMBRANE

Waterproof, windproof, heat-resistant. Trusted by global outdoor and sports brands worldwide.

Choose Application

Select the perfect membrane solution for your needs

Brand	Code	Application	Layers	Specs	Weight(gsm) ASTM D 3776	Thickness	Water Permeability ISO811	Breathability JIS L 1099-B1	Air Permeability ASTM D737
	MP25	Military + Professionals	2	Bicomponent PE/PET & FR PTFE	60.0 (+/-10%)	0.130mm	10000mm H²o	20000 g/m2/24hrs	0.c2 cfm 1.01/m²/sec

2 layer of PE/PET & eVent® FR PTFE membrane

Brand	Code	Application	Layers	Specs	Weight(gsm) ASTM D 3776	Thickness	Water Permeability ISO811	Breathability JIS L 1099-B1	Air Permeability ASTM D737
	MP25+	Military + Professionals	3	Bicomponent PE/PET & FR PTFE	77.0 (+/-10%)	0.198mm	15000mm H²o	15000 g/m2/24hrs	0.c2 cfm 1.01/m²/sec

3 layer of PE/PET & eVent® FR PTFE membrane

Brand	Code	Application	Layers	Specs	Weight(gsm) ASTM D 3776	Thickness	Water Permeability ISO811	Breathability JIS L 1099-B1	Air Permeability ASTM D737
	MP24	Military + Professionals	2	Bicomponent PE/PET & ePTFE	47.0(+/-10%)	0.145mm	10000mm H²o	30000 g/m2/24hrs	0.2 cfm 1.5 l/m²/sec

2 Layers of PE/PET & eVent® Oleo-phobic and air permeable ePTFE membrane

Brand	Code	Application	Layers	Specs	Weight(gsm) ASTM D 3776	Thickness	Water Permeability ISO811	Breathability JIS L 1099-B1	Air Permeability ASTM D737
	MP24+	Military + Professionals	3	Bicomponent PE/PET & ePTFE	67.0(+/-10%)	0.208mm	15000mm H²o	25000 g/m2/24hrs	0.150 cfm 0.762 l/m²/sec

3 Layers of PE/PET & eVent® Oleo-phobic and air permeable ePTFE membrane

Brand	Code	Application	Layers	Specs	Weight(gsm) ASTM D 3776	Thickness	Water Permeability ISO811	Breathability JIS L 1099-B1	Air Permeability ASTM D737
	MP27	Sports + General	2	PFAs Free PE/PET & PA	51.0 (+/-10%)	0.124mm	10000mm H²o	30000 g/m2/24hrs	0 cfm 0 l/m²/sec

2 layer of PE/PET & eVent® StormST Polyamide membrane

Brand	Code	Application	Layers	Specs	Weight(gsm) ASTM D 3776	Thickness	Water Permeability ISO811	Breathability JIS L 1099-B1	Air Permeability ASTM D737
	MP27+	Sports + General	3	PFAs Free PE/PET & PA	73.0 (+/-10%)	0.205mm	15000mm H²o	20000 g/m2/24hrs	0 cfm 0 l/m²/sec

3 layer of PE/PET & eVent® StormST Polyamide membrane

Brand	Code	Application	Layers	Specs	Weight(gsm) ASTM D 3776	Thickness	Water Permeability ISO811	Breathability JIS L 1099-B1	Air Permeability ASTM D737
	DV22+	General	2	PFAs Free PE/PET & TPU	62.0 (+/-10%)	0.195mm	10000mm H²o	25000 g/m2/24hrs	0 cfm 0 l/m²/sec

2 layer of PE/PET & TPU membrane

Brand	Code	Application	Layers	Specs	Weight(gsm) ASTM D 3776	Thickness	Water Permeability ISO811	Breathability JIS L 1099-B1	Air Permeability ASTM D737
	DV22AB	General	2	PFAs Free PE/PET & TPU	64.0 (+/-10%)	0.190mm	10000mm H²o	25000 g/m2/24hrs	0 cfm 0 l/m²/sec

2 layer of PE/PET & TPU membrane (Anti-Bacterial)

Brand	Code	Application	Layers	Specs	Weight(gsm) ASTM D 3776	Thickness	Water Permeability ISO811	Breathability JIS L 1099-B1	Air Permeability ASTM D737
	AD21TPU	General	1	TPU	83.0 (+/-10%)	0.408mm	10000mm H²o	2000 g/m2/24hrs	0 cfm 0 l/m²/sec

1 layer of Adhesive-TPU membrane

Brand	Code	Application	Layers	Specs	Weight(gsm) ASTM D 3776	Thickness	Water Permeability ISO811	Breathability JIS L 1099-B1	Air Permeability ASTM D737
	AD21PU	General	1	PU	48.0 (+/-10%)	0.186mm	10000mm H²o	10000 g/m2/24hrs	0 cfm 0 l/m²/sec

1 layer of Adhesive-PU membrane

Tech Specs

Revolutionary membrane technology with highlighted features and detailed
specifications

Request Information

100% Waterproof Protection

Complete barrier against moisture while maintaining exceptional
breathability

Heat Resistant up to 150°C

Extreme temperature tolerance engineered for demanding
professional applications

Heat-Sealed Construction

Advanced no-stitch technology ensures complete leak-proof
performance
